PL Light NXT LP DE 1000W 120/240V ALPHA
Low Ceiling High Performance Lighting
Engineered specifically for low ceiling applications, the HSE NXT-LP offers growers the same industry-leading performance they have come to expect from the NXT family of products — without compromise.
- Dimmable Electronic Ballast
- Engineered for Optimal Thermal Performance
- High-Output Double-ended Electronic Lamp
- Low profile close to ceiling mounting
- Optimum Light Output and Uniformity
Engineered specifically for low ceiling applications, the NXT LP has an ultra low-profile design allows for more space between the fixture and the surface of the crop.
Given the dimensional nature of taller crops, directing light deep within the canopy to reach the lower leaves is typically a challenge. The NXT-LP with Beta Reflector delivers a more focussed field of illumination between 0 & 45 degrees in the lower hemisphere, producing uniformly deep light penetration into the canopy below, with a phenomenal efficiency* of 92.0%.
TECHNICAL SPECIFICATIONS† 1,000W |
||||
| Rated Main Voltage | 208V | 240V | 277V | 347V |
| Input Current | 5.10A | 4.42A | 3.77A | 3.00A |
| Power Factor | > 0.98 | |||
| Input Frequency | 50/60Hz | |||
| Actual Input Power | 1,060W | 1,060W | 1,045W | 1,040W |
| Lamp Type | HPS 1,000W 400V Electronic | |||
† Accurate to ± 10%
TECHNICAL SPECIFICATIONS† 600W |
|||||
| Rated Main Voltage | 120V | 208V | 240V | 277V | 347V |
| Input Current | 5.5A | 3.04A | 2.65A | 2.29A | 1.84A |
| Power Factor | > 0.98 | ||||
| Input Frequency | 50/60Hz | ||||
| Actual Input Power | 660W | 632W | 632W | 632W | 640W |
| Lamp Type | HPS 600W 400V Electronic | ||||
† Accurate to ± 10%
DIMENSIONS |
|
| x = length | 21.25 in. (53.98 cm) |
| y = width | 11.00 in. (27.94 cm) |
| z = height | 7.50 in. (19.05 cm) |
| weight | 10.00 lb. (4.54 kg) |
ENVIRONMENT
The product is meant for use in climate controlled rooms. The product may be used in damp environments. The product may not be used in wet environments or outdoors. The PL Light Systems HPS double-ended lamps function optimally when the ambient temperature is between 20 ~ 30° Celsius.
WARRANTY
Fixtures warrantied for three (3) years; electronic drivers three (3) years; lamps four (4) years or 10,000 burning hours, whichever comes first.
